2000 W continuous program power capacity
100 mm (4 in) copper voice coil
35 - 1500 Hz response
97 dB sensitivity
FEA optimized Neodymium magnet assembly
Double silicone spider with optimized compliance
Ventilated voice coil gap for reduced power compression
Teknik Özellikler:
Nominal diameter 380 mm (15.0 in)
Nominal impedance 8 Ω
Minimum impedance 6.2 Ω
Nominal power handling * 1000 W
Continuous power handling * 2000 W
Sensitivity (1W/1m) * 97.0 dB
Frequency range 35 - 1500 Hz
Voice coil diameter 100 mm (4.0 in)
Winding material Copper
Former material Glass Fibre
Winding depth 25 mm (1.0 in)
Magnetic gap depth 12 mm (0.5 in)
Flux density 1.2 T
Design
Surround shape Triple Roll
Cone shape Radial
Magnet material Neodymium Inside Slug
Spider Double Silicone
Pole design T-Pole
Woofer cone treatment WP Waterproof Front Side
Recommended enclosure 100.0 dm3 (3.53 ft3)
Recommended tuning 40 Hz
Parameters *
Fs 33 Hz
Re 5.1 Ω
Qes 0.23
Qms 4.3
Qts 0.22
Vas 139.0 dm3 (4.9 ft3)
Sd 855.0 cm2 (132.5 in2)
η₀ 2.1 %
Xmax 9.0 mm
Xvar 11.0 mm
Mms 173 g
Bl 28.0 Txm
Le 1.9 mH
EBP 143 Hz
Mounting And Shipping Info
Overall diameter 393 mm (15.5 in)
Bolt circle diameter 374 mm (14.7 in)
Baffle cutout diameter 354.0 mm (13.9 in)
Depth 181 mm (7.1 in)
Flange and gasket thickness 16 mm (0.62 in)
Air volume occupied by driver 6.0 dm3 (0.21 ft3)
Net weight 8.6 kg (18.9 lb)
Shipping units 1
Shipping weight 10.0 kg (22.0 lb)
Shipping box 420x420x200 mm (16.5x16.5x7.9 in)
