CPX™ 1

Channels (Input) 2
Channels (Output) 2
Power per Channel @ 2 Ω 300 W
Power per Channel @ 4 Ω 480 W
Power per Channel @ 8 Ω 290 W
Power per Channel @ 4 Ω Bridged 600 W
Power per Channel @ 8 Ω Bridged 960 W
Topology Class AB
Minimum Load Impedance 2 Ω
Frequency Response 12 Hz – 35 kHz; +0, -2 dB @ 1W
Input Connectors 1 x Barrier Strip, 2 x XLR-1/4″ Combo & 4 x 1/4″ Jack
Output Connectors 2 x Binding Post, 3 x 4-pin Twist-Lock
Color Black
Rack Mount (19″) Yes (2U)
Net Weight 40.0 lbs (18.20 kg)
Product Height 3.50″ (89 mm)
Product Width 19.00″ (483 mm)
Ürün Derinliği 15,50″ (380 mm)
AC Güç Girişi Çift Voltaj – 115VAC veya 220-240VAC, 50/60 Hz
