Rated Output (RMS): 240W
Frequency Response
CH1~CH6: 120Hz-10kHz
Telephone In: 330Hz-3.3kHz
Link In: 80Hz-12kHz
Amp In: 60Hz-15kHz
Total Harmonic Distortion(T.H.D)
CH1~CH6, Phono: Less than 1%
Telephone In, Link In: Less than 0.5%
Amp In: Less than 0.5%
Signal to Noise Ratio(S/N)
CH1~CH6: more than 50dB
Phono: more than 55dB
Telephone In, Link In: more than 65dB
Amp In: more than 95dB
Graphic Equalizer (100Hz, 330Hz, 1kHz, 3.3kHz, 10kHz): ±12dB
Input Sensitivity/Impedance
CH1~CH6: -70dB/600Ω
Phono: -54dB/600Ω
Link In: -20dB/15kΩ
Telephone In: EC/JAPAN : -2dB(0.775V)/600Ω USA/CANADA : -10dB(0.3V)/600Ω
Amp In: 0dB/4700Ω
Speaker Output/Impedance: EC/JAPAN : 240W / 4Ω(30V), 8Ω(43V), 21Ω(70V), 41Ω(100V) USA/CANADA : 240W / 4Ω(30V), 8Ω(43V), 21Ω(70V)
Amp Out/Impedance: 0dB/600Ω
Link Out/Impedance: -6dB/600Ω
Power Source: 100–120VAC or 220–240VAC; 50/60Hz (Supplied AC mains transformer depends on country requirements)
Power Consumption: 240W
Weight: 13.5kg/29.76lb
Dimensions: 420(W)x133(H)x320(D)mm/16.5(W)x5.2(H)x12.5(D)in
Operating temperature: -10°C ~ +40°C
