Konnektörler: RCA phono (S/PDIF)
Format: S/PDIF (24 bit), EIAJ CP-340, IEC 958
Sample Aralığı: 44.1 kHz, 48 kHz
Frekans Aralığı DIO: DC to 22/23.9 kHz ± 0.01 dB @ 44.1/48 kHz
Konnektörler, Balanslı: Mic.: XLR, line: 1/4″ phone jack
Empedans: Balanced/unbalanced Mic.: 3.6/1.8 kOhm, Line: 21/13 kOhm
Line input level @ 0 dBFS: +24 dBu to +0 dBu
Line Hassasiyeti @ 12 dB headroom: -12 dBu to +12 dBu
Mic. Tiz Hassasiyeti @ 0 dBFS: Pad off/on: 24 dBu/-4 dBu to -61 dBu/-41 dBu
Mic. Bormal Hassasiyeti @ 0 dBFS: Pad off/on: -14 dBu/6 dBu to -51 dBu/-31 dBu
Mic. Bass Hassasiyeti @ 0 dBFS: Pad off/on: -2 dBu/18 dBu to -39 dBu/-19dBu
Line, mic. @ min gain, dynamic range: > +92 dB, 20 Hz – 20 kHz
NF/Vi @ max. micamp. gain, Rg = 200 ohm: < +2 dB / -127.4 dBu
THD: < -100 dB (0,001 %) @ 1 kHz
Line Frekans Aralığı: +0/-0.1 dB, 20 Hz to 20 kHz
Mic. Frekans Aralığı, max gain: -1.5 dB @ 40 Hz, +0/-0.1 dB (200 Hz to 20 kHz)
Crosstalk: < -85 dB, 20 Hz to 20 kHz A to D conversion: 24 bit, 128 x oversampling bitstream
A'dan D delay: 0.65/0.70 ms @ S.R. = 48/44.1 kHz
D'den A conversion: 24 bit, 128 x oversampling bitstream
D'den A delay: 0.63/0.68 ms @ S.R. = 48/44.1 kHz
Konnektörler, Balanslı: 1/4″ TRS phone jack
Çıkış Empedansı: 40 ohm Balanced/unbalanced 20 dBu/14 dBu, R-load = 1200 ohm
Çıkış : variable up to +20 dBu Dynamic range: > +104 dB, 20 Hz to 20 kHz
THD: <-98 dB (0.0013 %) @ 1 kHz
Frekans Aralığı: 20 Hz to 20 kHz, +0/-0.3 dB
Crosstalk: <-100 dB, 20 Hz to 20 kHz
Uyumluluk: IEN 55103-1 and EN 55103-2 FCC part 15, Class B, CISPR 22, Class B
Ekran: 16x 2 character LCD Ekran
Güç Tüketimi: <15 W
Ana Voltaj: 100 to 240 VAC, 50 to 60 Hz (auto-select)
Kontrol Arayüzü
MIDI: In/out/thru: 5 pin DIN
Pedal: 1/4″ phone jack
Fiziksel Özellikler
Genişlik: 483 mm
Yükseklik: 44 mm
Derinlik: 195 mm
Ağırlık: 1.85 kg
