500 W continuous program power capacity
64 mm (2.5 in) aluminium voice coil
50 - 3000 Hz response
97 dB sensitivity
Neodymium magnet allows a very light yet powerful motor assembly
Ventilated voice coil gap for reduced power compression
Teknik Özellikler:
- Nominal diameter 250 mm (10.0 in)
- Nominal impedance 8 Ω
- Minimum impedance 7.0 Ω
- Nominal power handling * 250 W
- Continuous power handling * 500 W
- Sensitivity (1W/1m) * 97.0 dB
- Frequency range 50 - 3000 Hz
- Voice coil diameter 64 mm (2.5 in)
- Winding material Aluminium
- Former material Glass Fibre
- Winding depth 14 mm (0.55 in)
- Magnetic gap depth 8 mm (0.31 in)
- Flux density 1.25 T
- Design
- Surround shape Double Roll
- Cone shape Exponential
- Magnet material Neodymium Inside Slug
- Spider Single
- Pole design Straight Pole
- Woofer cone treatment TWP Waterproof Both Sides
- Recommended enclosure 26.0 dm3 (0.92 ft3)
- Recommended tuning 62 Hz
- Parameters *
- Fs 56 Hz
- Re 5.7 Ω
- Qes 0.29
- Qms 3.4
- Qts 0.26
- Vas 31.0 dm3 (1.1 ft3)
- Sd 320.0 cm2 (50.0 in2)
- η₀ 1.8 %
- Xmax 6.0 mm
- Xvar 7.0 mm
- Mms 37 g
- Bl 16.2 Txm
- Le 0.9 mH
- EBP 193 Hz
- Mounting And Shipping Info
- Overall diameter 261 mm (10.3 in)
- Bolt circle diameter 245 mm (9.6 in)
- Baffle cutout diameter 230.0 mm (8.8 in)
- Depth 113 mm (4.4 in)
- Flange and gasket thickness 13 mm (0.5 in)
- Air volume occupied by driver 1.5 dm3 (0.05 ft3)
- Net weight 2.9 kg (6.4 lb)
- Shipping weight 3.5 kg (7.7 lb)
- Shipping box 330x330x160 mm (13x13x6.3 in)
