2400 W continuous program power capacity
100 mm (4 in) copper voice coil
35 - 1000 Hz response
97 dB sensitivity
Aluminium demodulating ring allows a very low distortion figure
Double silicone spider with optimized compliance
Ventilated voice coil gap for reduced power compression
Teknik Özellikler:
Nominal diameter 460 mm (18.0 in)
Nominal impedance 8 Ω
Minimum impedance 6.2 Ω
Nominal power handling * 1200 W
Continuous power handling * 2400 W
Sensitivity (1W/1m) * 97.0 dB
Frequency range 35 - 1000 Hz
Voice coil diameter 100 mm (4.0 in)
Winding material Copper
Former material Glass Fibre
Winding depth 25 mm (1.0 in)
Magnetic gap depth 12 mm (0.5 in)
Flux density 1.1 T
Design
Surround shape Triple Roll
Cone shape Radial
Magnet material Ceramic
Spider Double Silicone
Pole design T-Pole
Woofer cone treatment TWP Waterproof Both Sides
Recommended enclosure 200.0 dm3 (7.06 ft3)
Recommended tuning 34 Hz
Parameters *
Fs 34 Hz
Re 5.1 Ω
Qes 0.37
Qms 7.2
Qts 0.35
Vas 212.0 dm3 (7.5 ft3)
Sd 1210.0 cm2 (187.6 in2)
η₀ 2.2 %
Xmax 9.0 mm
Xvar 11.0 mm
Mms 209 g
Bl 25.5 Txm
Le 1.6 mH
EBP 91 Hz
Mounting And Shipping Info
Overall diameter 460 mm (18.0 in)
Bolt circle diameter 440 mm (17.3 in)
Baffle cutout diameter 422.0 mm (16.6 in)
Depth 209 mm (8.2 in)
Flange and gasket thickness 16 mm (0.62 in)
Air volume occupied by driver 10.5 dm3 (0.37 ft3)
Net weight 13.0 kg (28.6 lb)
Shipping units 1
Shipping weight 14.4 kg (31.7 lb)
Shipping box 500x500x250 mm (19.7x19.7x9.8 in)
