400 W continuous program power capacity
50 mm (2 in) copper voice coil
70 - 3000 Hz response
96.5 dB sensitivity
Neodymium ring magnet assembly
Shorting copper cap for extended HF response
Ventilated voice coil gap for reduced power compression
Teknik Özellikler:
- Nominal diameter 200 mm (8.0 in)
- Nominal impedance 8 Ω
- Minimum impedance 7.7 Ω
- Nominal power handling * 200 W
- Continuous power handling * 400 W
- Sensitivity (1W/1m) * 97.0 dB
- Frequency range 70 - 3000 Hz
- Voice coil diameter 51 mm (2.0 in)
- Winding material Copper
- Former material Glass Fibre
- Winding depth 19 mm (0.73 in)
- Magnetic gap depth 10 mm (0.4 in)
- Flux density 1.3 T
- Design
- Surround shape Double Roll
- Cone shape Exponential
- Magnet material Neodymium Ring
- Spider Single
- Pole design T-Pole
- Woofer cone treatment TWP Waterproof Both Sides
- Parameters *
- Fs 74 Hz
- Re 5.2 Ω
- Qes 0.19
- Qms 2.7
- Qts 0.17
- Vas 11.0 dm3 (0.4 ft3)
- Sd 220.0 cm2 (34.1 in2)
- η₀ 2.4 %
- Xmax 6.0 mm
- Xvar 6.0 mm
- Mms 28 g
- Bl 18.9 Txm
- Le 0.4 mH
- EBP 389 Hz
- Mounting And Shipping Info
- Overall diameter 225 mm (8.8 in)
- Bolt circle diameter 210 mm (8.3 in)
- Baffle cutout diameter 187.0 mm (7.4 in)
- Depth 100 mm (4.0 in)
- Flange and gasket thickness 11 mm (0.4 in)
- Air volume occupied by driver 1.1 dm3 (0.04 ft3)
- Net weight 3.0 kg (6.6 lb)
- Shipping weight 3.4 kg (7.5 lb)
- Shipping box 300x160x180 mm (11.8x6.3x7.1 in)
